Amorphous alloy transformers are advanced power transformers with core materials made of amorphous alloy, featuring **ultra-low no-load loss** as their core advantage. Their key characteristics span material properties, energy efficiency, and operational performance, making them widely used in energy-saving power systems.

　　1. Core Material Advantage: Amorphous Alloy

　　The core is made of iron-based amorphous alloy, which is formed by rapidly cooling molten alloy at a rate of 10⁶ °C/s. This non-crystalline structure gives it unique magnetic properties:

　　Low magnetic hysteresis loss The disordered atomic arrangement avoids magnetic domain friction caused by crystalline boundaries, significantly reducing energy loss during magnetic field changes.

　　High magnetic permeability It can be magnetized with a lower external magnetic field, further lowering no-load current and loss.

　　2. Outstanding Energy Efficiency: Ultra-Low No-Load Loss

　　Energy efficiency is the most prominent feature of amorphous alloy transformers, mainly reflected in no-load operation:

　　No-load loss reduction of 70%-80% Compared with traditional silicon steel sheet transformers, their no-load loss (energy consumed when the transformer is energized but no load is connected) is only 1/3 to 1/5. For example, a 10kV/500kVA amorphous transformer has a no-load loss of about 150W, while a silicon steel transformer of the same capacity is about 600W.

　　Long-term energy saving Since transformers operate at no load or light load for over 70% of the time (e.g., distribution transformers), the cumulative energy savings over their 20-30 year service life are substantial.

　　3. Operational Performance Characteristics

　　Low no-load current The no-load current is only 1/5 to 1/10 of that of traditional transformers, generally ≤1%, which reduces reactive power consumption and improves the power factor of the power grid.

　　Good noise control The amorphous alloy core has low magnetostriction (small dimensional changes during magnetization), so the operating noise is 3-5 dB lower than that of silicon steel transformers, usually ≤50 dB, making it suitable for residential or urban areas.

　　Strong overload capacity The core has good thermal stability, and the transformer can withstand short-term overload (e.g., 120%-150% rated load) without significant performance degradation, adapting to fluctuating load conditions.

　　4. Structural and Application Limitations

　　While it has obvious advantages, it also has some limitations due to material properties:

　　Brittle core material Amorphous alloy strips are thin (0.02-0.03mm) and brittle, requiring special clamping structures during manufacturing to avoid core damage from vibration or impact.

　　Higher initial cost The cost of amorphous alloy materials is about 2-3 times that of high-grade silicon steel sheets, so the initial purchase price is 15%-30% higher than traditional transformers. However, the investment can be recovered through energy savings in 3-5 years.

　　Sensitive to vibration The core is prone to increased loss if it is loose or vibrated for a long time, so it needs to be installed in a stable environment and regularly maintained.
