Amorphous alloy transformers are known for their ultra-low no-load loss, which is their core advantage over traditional silicon steel transformers. Their properties mainly manifest in four key aspects: energy efficiency, magnetic performance, mechanical characteristics, and operational reliability.

　　1. Core Property: Ultra-High Energy Efficiency

　　This is the most prominent feature, rooted in the unique structure of amorphous alloy materials.

　　Extremely low no-load loss: No-load loss (power loss when the transformer is energized but no load is connected) is only 20%-30% of that of traditional S9-series silicon steel transformers. For example, the no-load loss of a 1000kVA amorphous alloy transformer is about 0.35kW, while that of a silicon steel transformer of the same capacity is about 1.7kW.

　　Suitable for low-load scenarios: It is especially energy-efficient in areas with long-term low load rates (such as rural power grids, residential quarters, and commercial buildings), and can save tens of thousands of kWh of electricity annually for a single transformer.

　　2. Magnetic Performance: Excellent but Sensitive to Stress

　　Amorphous alloy has a disordered atomic structure, which gives it unique magnetic properties, but it also has obvious limitations.

　　High magnetic permeability: Under the same magnetic field intensity, its magnetic permeability is much higher than that of silicon steel sheets, which helps reduce magnetic flux loss and improve voltage stability.

　　Stress sensitivity: The magnetic properties are easily affected by mechanical stress (such as vibration, collision, or improper installation). Once the core is deformed, the no-load loss may increase by 10%-50%, so strict anti-vibration measures are required during transportation and installation.

　　3. Mechanical & Structural Characteristics

　　Its material properties determine special requirements for structural design.

　　Brittle material: Amorphous alloy sheets are very brittle and easy to crack when bent or impacted. Therefore, the core cannot be stacked manually; it must be processed by specialized automatic equipment to ensure integrity.

　　Larger volume: To compensate for the lower saturation magnetic density (about 1.5T, lower than 2.0T of silicon steel), the core cross-section of amorphous alloy transformers is usually 10%-20% larger than that of silicon steel transformers of the same capacity, resulting in a slightly larger overall size.

　　4. Operational Reliability & Environmental Adaptability

　　It performs well in daily operation but has certain requirements for the working environment.

　　Low noise: The no-load noise is about 3-5dB lower than that of traditional transformers (usually ≤50dB), which meets the noise standards of residential areas and hospitals.

　　Humidity sensitivity: The core insulation relies on a thin coating. In high-humidity environments (relative humidity >85%), the coating is prone to moisture absorption and aging, so it is more suitable for indoor or well-ventilated outdoor installations (equipped with rainproof covers).

　　Long service life: Under normal maintenance conditions (regular inspection of core insulation and cooling systems), the service life can reach 25-30 years, which is equivalent to that of high-quality silicon steel transformers.
